Bundle Extractor SD120-6E
CHARACTERISTICS
• Good safety and high structural strength. The machine has been checked for structural strength by the Department of Concrete Structures, Dalian University of Technology, and has been optimized for structural design. It not only meets the requirement of structural strength, but also makes the weight as light as possible.
• Simple and practical operation can greatly reduce the labor intensity of field workers and improve labor efficiency.
• High applicability, one type of machine can meet the drawing and assembling requirements of various types of heat exchanger tube bundle.
• Hydraulic connection and adjustment, the connection and adjustment process is reliable and easy to operate.
• Use chain to draw the tube bundle, with strong power. The drawing and assembling is smooth and fast.
• Manual, remote and wire control systems ensure the safety of operators and are flexible and convenient to use.
• Low failure rate, good maintainability. In the design, the harsh site environment and the inevitable strong collision are fully considered, the vulnerable parts are reliably protected and anti-pollution isolation is trolleyried out. So the failure rate is very low. All parts of the machine are standard and can be easily purchased even if damaged.
Power supply
• The power supply of the machine is three-phase power, voltage: 380V(440V)±10 frequency:50Hz(60hz)(the power supply is determined according to the power supply voltage of the local country)
Bundle Extractor | 20t Technical specifications :
| Pipe bundle length（mm） | 6000 |
|
Pipe bundle diameter (mm) |
within Φ1200 |
|
Maximum force (T) |
20 |
|
Maximum load (T) |
20 |
|
Boundary dimension (length × width × height) mm |
9600*1400*1150 |
